High performance, high sound quality, impossible extreme challenge! Audio centron ID series cellular dynamic drive makes it possible. ID series because of its very high performance, innovative technology determines their attractive sound characteristics, making bass sound very dynamic and natural.
Cellular dynamic drive is a technology designed to improve the dynamics and efficiency of amplifiers. A special processor combined with a high-speed ID converter can produce very high efficiency in the range of more than 80%. The difference is that there is no fault caused by the switching process and the resulting distortion in the output signal.
Cellular dynamic drive is a technology to improve sound quality in high performance dynamics. The power with the best SOA limit is used in the ID endpoint, and the adhesion coefficient is significantly reduced, which is why the last level has clear, high resolution high fidelity sound.
ID has many protective circuits to prevent deformation and damage and ensure safe operation.
Stereo Power: (8 Ω) 2 × 1380W;
Stereo Power: (4 Ω): 2 × 2760W;
Stereo Power: (2 Ω): not applicable;
Single bridge power supply: (8 Ω): 3660W;
Bridge single power supply: (4 Ω): not applicable;
SNR: 106db
Conversion rate: 80V
Damping coefficient: 550:1
Frequency response: + / 1-0.1db, 20Hz-20KHz
Total harmonic distortion: ≤ 0.01% rated power @ 1kHz;
IMD: ≤ 0.01% rated power @ 8 Ω;
Input sensitivity: 0.775v/1.0v/1.55v;
LPF:20Hz-180Hz Effective
HPF:130Hz-20kHz Effective
Input impedance: 10 / 20K ohm, unbalanced or balanced
Input CMRR: ≤ - 75db
Crosstalk: ≤ - 70dB
LEP indicator: signal, protection, detection, limit / limit
Power supply: AC: 220-230v, 50Hz / 60Hz
Net weight: 14.8kg;
Dimensions (W x D x H): 482x377.5x88 mm
